Value Stream Mapping Confusion

By Ron Updated on February 26th, 2021

value stream mapping confusionWhen drawing value stream maps there can be confusion regarding the different “times” that are measured and, in some cases, calculated. I recently came up against this myself and thus want to share some tips with you all.

Cycle Time

First, let’s talk about cycle time (CT). You can think of cycle time as the time it takes a worker to go through all the work elements before repeating them again on another part. In most situations this will be the point where the product is being changed closer to the way the customer wants it. You measure cycle time with a stopwatch.

Production Lead Time

Next, let’s talk about Production Lead Time (PLT). This is the one that causes the most confusion, especially from IE’s not sold on this whole VSM thing (you know who you are!). The basic premise behind PLT is simple. PLT is the estimated time it might take for one piece to move from the receiving docks to the shipping docks. You can also think of it as how long it takes to return your investment for purchased raw material.

Let’s use an example.  Note: Days of Supply = WIP (pieces) / Daily Demand

If, after examining the inventory stacked up around your plant in a particular value stream, you determine there are 32 days’ supply of inventory (i.e. 8 days’ supply before process A, 12 days’ supply before process B, and 12 days’ supply before process C) you should expect a new piece to take around 32 days to make it through all that inventory.  This assumes a serial process; meaning we must go through A first, then B, and then C.

Just an Estimate

Remember, PLT is just an estimate and when things like expediting take place (and they often do) things might move through the value stream at a different pace. A cool trick to test this whole theory is to go out and mark your initials on some raw material at the start of the process and track how long it takes to pop out at end of your process. Just mark it in a spot the customer won’t see and that won’t get painted or machined off!

  1. Mark Graban

    February 21, 2007 - 8:25 pm

    Don’t you hate it how “cycle time” is also used in terms of what you call “production lean time?”

    Having to say “which cycle time do you mean?” gets irritating. Of course, in the auto context, a 45 second cycle time, it’s obvious that it’s the repeated cycle, not the elapsed time through the total process.

  2. Ron Pereira

    February 22, 2007 - 7:10 am

    Yeah, if there is one weakness to Lean and Six Sigma its with all the lingo and buzz terms. In the end though as long as people understand what it is they mean by these buzz terms and lingo things can be sorted out. Of course, when someone just starts dropping terms left and right since they just read a book things can get dangerous!
